Body temperature detection dynamic face recognition tablet is an access control product developed using the latest face mask recognition algorithm and thermal imaging body temperature detection technology. The system supports automatic switching in 1: 1 and 1: N modes. Based on the Android system environment, it has the features of face recognition speed and temperature detection in seconds, high accuracy, high security, and good stability. It now can widely be applied for public access control projects for better prevention of COVID-19 as it can detect face+body temperature(thermal body heat)+face mask indication to alert people as long as public health and safety require as new coronavirus is recently under a tough situation.

Applicable scene
Residential quarters, office buildings, schools, government units, tourist attractions, factory sites, kindergarten,etc. Applied equipment like turnstile gates, speedstiles, speed gates, flap barriers,full height turnstile gates/revolving doors, sliding gates, hidden gates, interlock gates, immigration gates, etc.

CPU

ARM RK3399 (28 nm) 6-core 64-bit processor, large-core Cortex-A72 (dual-core) + small-core Cortex-A53 (quad-core) clocked at 2.0GHz

RAM

RAM 2GB

Storage

ROM 16GB

operating system

Android 7.1.2

Display

8-inch LCD display with resolution:1280*800@60HZ

Appearance material

Aluminum alloy

Performance



Recognition height

1.2-2.2 M

Recognition distance

0.5-3 M

Body temperature detection distance

0.5M

Identification technology

Support mask recognition + infrared body temperature detection

Face angle

30 degrees left and right, 30 degrees up and down

Identification technology

Embedded visible light detection and recognition, adapt to the indoor and outdoor environment, with dynamic face recognition

Recognition time

Detection and tracking 20ms, compared with 80ms / thousand people, feature extraction 300ms

Status display

Name body temperature broadcast display, custom information broadcast display

Body temperature detection dynamic face recognition tablet is an access control product developed using the latest face mask recognition algorithm and thermal imaging body temperature detection technology. The system supports automatic switching in 1: 1 and 1: N modes. Based on the Android system environment, it has the features of face recognition speed and temperature detection in seconds, high accuracy, high security, and good stability.It now can widely be applied for public access control projects for better prevention of COVID-19 as it can detect face+body temperature(thermal body heat)+face mask indication to alert people as long as public health and safety requires as new coronavirus is recently under a tough situation.

Applicable scene
Residential quarters, office buildings, schools, government units, tourist attractions, factory sites, etc.

CPU

ARM RK3399 (28 nm) 6-core 64-bit processor, large-core Cortex-A72 (dual-core) + small-core Cortex-A53 (quad-core) clocked at 2.0GHz

RAM

RAM 2GB

Storage

ROM 16GB

operating system

Android 7.1.2

Display

8-inch LCD display with resolution:1280*800@60HZ

Appearance material

Aluminum alloy

Performance



Recognition height

1.2-2.2 M

Recognition distance

0.5-3 M

Body temperature detection distance

0.5M

Identification technology

Support mask recognition + infrared body temperature detection

Face angle

30 degrees left and right, 30 degrees up and down

Identification technology

Embedded visible light detection and recognition, adapt to indoor and outdoor environment,with dynamic face recognition

Recognition time

Detection and tracking 20ms, compared with 80ms / thousand people, feature extraction 300ms

Status display

Name body temperature broadcast display, custom information broadcast display
