FB60 OEM Design For Solo

Optical flap gates offer standardized access for the evacuation of buildings in the event of an emergency and/or a wider walkway for people with reduced mobility and for service personnel. These gates are used inside buildings in many market segments such as industry, service, leisure, administration, banks, insurance, airports and museums...flexible for both normal,heavy laggages and handicap required passagers.

Please feel free to contact us

Success! Message received.



Main characteristics of Sweeper Gate are:

  • Wide swing walkway adapted to the mobility-impaired that is ideal for wheelchairs, large carts or wide objects

  • Streamlined and elegant oval design that integrates well into both prestigious lobbies yet robust enough for your harsh industrial environments



Other advantages :



Security

  • Pivoting obstacles that can be locked mechanically and electrically into a closed position to efficiently block unauthorized uses

  • Audio and visual alarms



Safety

  • Mechanical opening in case of emergency or power outage

  • Swing-off obstacle for emergency evacuations (option)



Aesthetics

  • Streamlined and elegant oval design that integrates into prestigious lobbies yet robust and durable for your harsh industrial environments

  • Precise backlit pictograms for safe pedestrian flow

  • Quality assembly and detailed manufacturing



Customisation

  • Combination of wide and narrow security entrance lanes allows you to configure the installation to your needs

  • Aesthetic and functional customisation to meet your specific needs

  • Vast selection of options and accessories



Reliability & Performance

  • Third generation of security entrance lanes based on years of our professional experience and over  millions of daily users

  • Long life cycle and low cost of ownership



The principal market segments concerned by ATB' sweeper gate are:


Wide bi-directional swing gate adapted to the mobility-impaired that is ideal for large carts or wide objects. They provide a complete solution, in that they are adapted to the mobility-impaired and integrate perfectly into prestigious and luxurious lobbies.

Typical customer segments include:

  • Banks and insurance companies

  • Government buildings and institutions

  • Office buildings, head offices, administrative sites

  • Schools, universities and colleges

  • Sensitive sites: military bases, nuclear plants, pharmaceutical companies, data centers

  • Industrial and manufacturing facilities

  • Airports, etc.



Parameter :

Bidirectional swing gate compliant for the mobility-reduced, equipped with a tempered glass swing obstacle

Overall Dimensions :
(Length x Width x Height)

1400 x 340 x 980mm

Lane Width :550-900 mm

Throughput :30-45people/minute, depending on the access control system

Opening/closing speed :1sec

MCBF (Mean Cycle Before Failure) :3, 000,000

Adapted to the reduced-mobility :Yes

Operating Temperature :-20° C to + 60° C

Basic Finishes (3) :Cabinet: Stainless steel, # 400 brush finish
Top Cover: Brush treatment or Black laminate
Obstacles: 12 mmm clear tempered glass /acrylic

Control :Compatible with all access control systems

Notes
(2) With preventive maintenance
(3) Other optional finishes are also available
